Name: Bench Clamp Vise High Precision Clamping Vise 6 Inch Jaw Width CNC Vise Fixed Jaw
Brand: VEVOR
SKU: TQ6YCJMJYHQHT0001V0
Price: 154.99 EUR
Availability: OutOfStock
Rating: 4.8 (387 reviews)

Bench Clamp Vise High Precision Clamping Vise 6 Inch Jaw Width CNC Vise Fixed Jaw

154₉₉ €

Earn at least 13_,72 € (1372 points) back calculated at checkout. Details

Price including VATSee details

Save up to 15% with PRO price. Sign up for free PRO Account.

Exclusive 5_,00 € off for your first three orders on the App.

Download Now

Exclusive 5_,00 € off for your first three orders on the App.

Scan the QR code to download

Free delivery to Ireland

Get it Thur. Mar. 6 - Tues. Mar. 11 Details

Shipping Rates & Policies

All products are currently free shipping, except in some remote areas. please verify your delivery address to ensure accurate shipping cost information is displayed.

Unless noted otherwise in the ordering pipeline, ships all items within two days of receiving an order.

The delivery date is for reference only and may be adjusted according to the delivery address. Please refer to the actual delivery time.

specification: 160 mm

80 mm
5"
125 mm
100 mm
160 mm
120 mm

Material: Gray Cast Iron

Alloy Steel
Nodular Cast Iron
Gray Cast Iron

Sold Out

About this item

【PREMIUM QUALITY STRUCTURE】 - 45# steel jaws, after high-frequency quenching, undergo improving the wear resistance and service life of the jaws. Vise body for the HT250 high quality cast iron forging, which has good toughness, high strength, and durability.
【POWERFUL CLAMPING FORCE】 - Vise guide surfaces are finely polished, smooth surface. When clamping the workpiece, the movement is stable, the positioning is accurate, and the clamping force can reach up to 19 KN, which is suitable for workpieces of different sizes.
【HIGH ACCURACY SCREW】 - The closed design protects the screw rod and prevents the entry of iron pins and other debris, which is convenient for maintenance and cleaning. The vise can be used not only horizontally, sideways, but also vertically, and its accuracy remains at 0.0008" (0.02 mm).
【HUMANIZED DESIGN】 - Our vises are detachable and can be quickly changed. The unique downward pressure design prevents the workpiece from floating when clamped. The hardened swivel handle is a universal joint structure, easy operation, flexible, and convenient to use.
【MULTIFUNCTIONAL TOOL】 - Jaw Width: 6" (150 mm), Jaw Opening: 6.3" (160 mm). Milling Vise is an essential tool for fitters. Most work of the fitters is running by using the clamping vise such as sawing, filing, chiseling, and some assembly and removal jobs.

See More See Less

VEVOR milling vice: 6" gray cast iron cnc vise with solid casting and high precision

VEVOR is a leading brand that specializes in equipment and tools. Along with thousands of motivated employees, VEVOR is dedicated to providing our customers with tough equipment & tools at incredibly low prices. Today, VEVOR has occupied markets of more than 200 countries with 10 million plus global members.

Why Choose VEVOR?

Premium Tough Quality
Incredibly Low Prices
Fast & Secure Delivery
30-Day Free Returns
24/7 Attentive Service

Why Choose VEVOR?

Premium Tough Quality
Incredibly Low Prices
Fast & Secure Delivery
30-Day Free Returns
24/7 Attentive Service

VEVOR milling vice with lever, mounting plate, and hardware screws.

6" Multifunction Precision Lockdown Vise

During workshop operation, many workpieces minor damage due to their materials or excessive force, which caused work delays or economic losses. Therefore, to avoid damage to your workpiece, we recommend that you use the vise to clamp the workpiece. Our vise has a strong clamping force and can hold the workpiece very firmly. It can ensure the stability of the workpiece and avoid damage

Premium Quality Structure
Powerful Clamping Force
High Accuracy Screw
Humanized Design
Multifunctional Tool

VEVOR milling vice ht250 cast iron with blue highlights and mechanical parts.

Durable Material

The vise is made of HT250 high-quality cast iron, with strong toughness, high tensile strength, and wear resistance. Internal refine grinding treatment, smooth use, no jamming, rust, and corrosion resistance.

VEVOR milling vice with closed design and enhanced durability.

Hardened Clamping Jaw

The jaws are thickened and finely ground, and the maximum clamping force can reach 29 KN. The lockdown vise machine adopts a fully enclosed design, and iron filings are not easy to enter, which improves the service life of the vise.

VEVOR milling vice showing precision thread and adjustment handle.

Quality Lead Screw

The thread pitch of the ladder screw is larger than the standard screw. The surface is quenched, turned, and ground. It is more wear-resistant, durable, and corrosion-resistant than the ordinary screw, and has higher accuracy.

Adjustable Handle

The universal joint handle is ductile iron material, which is not easy to rust and is flexible and durable. You can precisely adjust the gripping force of the jaws through the handle, and complete the workpiece clamping work excellently.

VEVOR milling vice with precision clamping jaws on a blue background.

Precision Design

The guide rail surface is refined ground, seamless contact surface, and the positioning is more accurate. Compared with a standard vise, it can be used upright without affecting the accuracy of clamping the workpiece.

VEVOR milling vice in various industrial machinery environments.

Wide Application

Precision milling vise is the main accessory of precision milling machine and NC/CNC machine tool. Suitable for finishing milling machines, drilling machines, and precision parts.

VEVOR milling vice with adjustable handle and included mounting accessories.

Package Content

1 x 6" Bench Clamp Vise Fixed Jaw
1 x Handle
1 x Manual

VEVOR milling vice with dimensions 10.1"x 5.9"x 17.6".

Specifications

Type: Bench Vise
Jaw height: 1.8" (45 mm)
Jaw width: 6" (150 mm)
Jaw opening: 6.3" (160 mm)
Jaw material: 45# steel
Body material: HT250 gray cast iron
Wrench material: QT500 ductile iron
Vise Height: 4.7" (120 mm)
Max Clamping force: 29 KN
Gross weight: 55.6 lbs (25.2 kg)
Package dimensions (L x W x H): 18.1" x 12.6" x 6.7" (46 x 32 x 17 cm)

Specification

Type: Bench Vise

Jaw height: 1.8" (45 mm)

Jaw width: 6" (150 mm)

Jaw opening: 6.3" (160 mm)

Jaw material: 45# steel

Body material: HT250 gray cast iron

Wrench material: QT500 ductile iron

Vise Height: 4.7" (120 mm)

Max Clamping force: 29 KN

Gross weight: 55.6 lbs (25.2 kg)

Package dimensions (L x W x H): 18.1" x 12.6" x 6.7" (46 x 32 x 17 cm)

Manual: Download Link

Surprisingly well made. A little deburring and corner breaking required (plus ca change) but the vice trammed in easily on the mill table and had virtually no jaw lift. For the price I'd say this was a really good deal.

Nagyon szépen megmunkált készülék! Minőségben össze sem hasonlítható a naróasztallal! Ez egy össze köszörült felületű befogó készülék. Forditható talp nélkül is felfogható!

I've used this vise for a while now and can say that I am pleased with it. For the price the quality is great, the vise jaws are precisely machined, as well as the milled keyways with keys underneath the vise which perfectly fits my milling table, making it super easy to perfectly align the vise to the table, great feature! The base of the vise has small walls that contains flood coolant which I run on my mill, these walls was not quite high enough so i modified it a little to make them higher which works great. Slightly higher walls on the base would be amazing. However it might not be made to run flood coolant but only to collect small amounts of oil and chips, this it works great for. the only drawback I've noticed is that chips from drilling tends to collect inside the vise and jam up either the screw or ways, this can make it difficult to turn the handle and move the vise jaw. I use a small brush to clean these chips away. Overall very pleased with the quality of this vise and for the price its amazing. Recommended.

Customer Reviews

4.8 Out of 5

Based on 387 reviews

Ratings by Features

Price 4.8
Quality 4.6
Features 4.6
Easy to Use 4.7
See More See Less

387 Review(s)

Text, image, video

Photos Only

Videos Only

All star

5 star Only

4 star Only

3 star Only

2 star Only

1 star Only

Most Recent

Most Helpful

Clear filters

DomesticusDom

Nice for the price

Got this for my homemade milling machine and it works nicely some burr's and sharp edges that had to be filed off other than that works great.

Helpful Sending feedback... Thank you for your feedback. 0 people found this helpful

Mario

Best price/performance vise on the market!! I wasn't put it to my CNC yet, but it is really serious pice of iron. Thx

Stephen Davey

Zverak

Super pomôcka. Jednoduchá manipulácia. Aj keď prišlo trocha buchnute pravdepodobne dopravca. Na funkčnosti sa nič nemenilo.

Zoltán

Sopron

Cvetko

Tepanje

Primež sem kupil za na rezkalni stroj. Izdelek je zelo natančno narejen in robusten. Primeren je tudi za na vrtalni stroj.

Bjørn Kolbeinsen

Hobby

Bedre enn forventet til en meget behagelig kostnad. Godt laget med god presisjon og nøyaktighet. Anbefales

tobby

Solid vise

Ben

Engineer

Very good quality, very good price. Very satisfactory purchase. I have made several Vevor purchases and they are all goor value and high performance !

Svenne

Swedish customer

Fast delivery, Overall good quality, Sharp edges needed beburring, Very good customer support, Recommend the vise
